SPECIFICATIONS
Model and dimensions ORBIT 2.5 Series for Beam Recessed and Slot
PROFILE DIMENSIONS
DATA TABLE
| BEAM | RECESSED | SLOT | |||
| Optic Module LED Engine |
Proformax S | CRI | 90+ | ||
| Lumen Maintenance | 82,000 Hours | ||||
| Warranty | 7 years | ||||
| Dimensions | 2.5 series | 2.8″ x 5.11″ | 3.81″ x 3.93″ | 2.8″ x 3.93″ | |
| Weight per (LM) | 2.5 series | 3.17lbs per feet | 2.68lbs per feet | 2.82lbs per feet | |
| IP Rating | IP20 (dry indoor application only) / Optional IP55 available | ||||
| Compatible ceiling type | Suitable for gyprock (drywall) ceilings, metal pan, concrete, timber and T bar grid ceilings | ||||
| Mounting | Surface mounting / Wire suspension | Drywall clips | Surface mounting / Wire suspension | ||
| Diffusers | Plexiglass | ||||
| Colours | Textured white / Textured black / Silver powder-coat | ||||
| Control | Fixed output / Dali – 2 / 0-10y (US market only) | ||||
| Orbit profiles are pre-configured versions of the loop range. To view on the Xero website go to xerolightingusa.com/orbit-series/ For more information on customisable loop products please visit xerolightingusa.com/contact to speak with a local Specification Representative. |
|||||
| Photometrics Please visit xconfigurator.xerolighting.com for the latest and most up to date IES photometric files |
|||||
SPECIFYING YOUR ORBIT RING
MOUNTING OPTIONS
