PRODUCT OVERVIEW

XTA |1.5 Square IP55 – Size: 40 Wide x 46mm Highcontinuous with remote gear

XTA 1 5 Square IMG1
XTA 1 5 Square IMG2

FEATURES
The XTA 1.5 IP55 series is a narrow body profile that has superior optics, gasketed section joins, unlit bends, and removable gear trays that can be upgraded in the future.

WARRANTY
All XTA products come with a 7-year standard warranty using Proformax light engines, or the 10-year advanced industry-leading warranty using Xeramix1.
Xero also offers their optional 15-year warranty when you choose to select XeramixR.
Go to xerolighting.com/warranty for more details



DATA TABLE
LED Engine
4ft Length
1120mm
Luminous Flux
(Delivered Lumens)
LO
1900
HO
3500
Xeramix CRI 80+
Lumen Maintenance: 114,000 Hours ( L90 B10 @ 50º )
Proformax CRI: 90+
Lumen Maintenance: 82,000 Hours ( L80 B10 @ 35º )
Warranty Xeramix 10 years
Proformax 7 years
Electrical Power Consumption Between 20 and 45w/m
Voltage input range 120 – 277V
Control methods Dimming options for white light: 0-10V, DALI, DMX Optional RGB / Sunset
Dimming control DMX or DALI XI
Total harmonic distortion THD 9.8% max
Approvals UL / CE / CCC / AS:NZS / EMC
Physical Dimensions 40 X 46mm
Weight per metre 2.6kg (6Ibs) average weight
Housing Aluminium Extrusion with anodised or powder-coated finish
Downward diffuser
Connections
Frosted acrylic lens / Polycarbonate lens / microprism lens
Polarised electrical connection between gasket section joins
Compatible ceiling type suitable for gyprock (drywall) ceilings, metal pan, concrete, timber and T-bar grid ceilings
Mounting Field adjustable rollerball wire suspensions / rod suspensions / wall mounting / surface mount
Joiner options (Unlit Joins) corner 90º / Cross 90º / Tee 90º / Straight 180º join
Operating temperatures Xeramix = -25ºC to 50ºC (-13ºF to 140ºF)
Proformax = -25ºC to 35ºC (-13ºF to 95ºF)
Environment IP55 (Not in direct sunlight)
Minimum length adjustment Xeramix = 1mm Proformax = 25mm
LED board types Xeramix LED boards in 25 / 100 / 280 / 560mm lengths Zhaga compatible
Proformax LED boards in 50 / 280mm / 560mm lengths Zhaga compatible
PENDANT LENGTHS
DESCRIPTION
PENDANT LENGTHS
total luminaire length in mm 590 870 1150 1430 1710 1990 2270 2550 2830 3110 3390
total luminaire length in inches 23 34 45 56 67 78 89 100 111 122 133
‘560 board multiples 1 1.5 2.0 2.5 2.0 3.5 4.0 4.5 5.0 5.5 6.0
CONTINUOUS RUNS
DESCRIPTION
CONTINUOUS RUNS
total luminaire length in mm 3670 3950 4230 4790 5070 5350 5630 5910 6190 6470 6750
total luminaire length in inches 144 155 166 177 188 199 210 232 243 254 265
‘560 board multiples 6.5 7 7.5 8.0 8.5 9.0 9.5 10.0 10.5 11.0 11.5
DESCRIPTION
CONTINUOUS RUNS
total luminaire length in mm 7030 7310 7590 7870 8150 8430 8710 8990 9270 9550 9830
total luminaire length in inches 276 287 298 309 320 331 342 353 364 375 386
‘560 board multiples 12.0 12.5 13.0 13.5 14.0 14.5 15.0 15.5 16.0 16.5 17.0
DESCRIPTION
CONTINUOUS RUNS
total luminaire length in mm 10110 10390 10670 10950 11230 11510 11790 12070 12350 12630 12910
total luminaire length in inches 397 408 419 430 441 452 463 474 485 496 507
‘560 board multiples 17.5 18.0 18.5 19.0 19.5 20.0 20.5 21.0 21.5 22.0 22.5
DESCRIPTION
CONTINUOUS RUNS
total luminaire length in mm 13190 13470 13750 14030 14310 14590 14870 15150 15430 15710 15990
total luminaire length in inches 518 529 540 551 562 573 584 595 606 617 628
‘560 board multiples 23.0 23.5 24.0 24.5 25.0 25.5 26.0 26.5 27.0 27.5 28.0
DESCRIPTION
CONTINUOUS RUNS
total luminaire length in mm 16270 16550 16830 17110 17390 17670 17950 18230 18510 18790 19070
total luminaire length in inches 639 650 661 672 683 694 705 716 727 738 749
‘560 board multiples 28.5 29.0 29.5 30.0 30.5 31.0 31.5 32.0 32.5 33.0 33.5

All the above lengths are for Non-IP rated systems only. Lengths vary slightly when IP rated systems are selected.
Please consult your local Xero representative for details

CUSTOM LENGTHS
CUSTOM LENGTHS
Custom lengths for Xeramix are available in 0.0393701” [1mm] increments above the minimum pendant length of 23” [590mm]
Custom lengths for Proformax are available in 0.984252” [25mm] increments above the minimum pendant length of 23” [590mm]

The XTA 1.5 series is a narrow body profile that has superior optics and Xero’s patented Speed join system that enables truly “light leak free joins” and removable
gear trays that can be upgraded in the future. The 90° and 180° joiners that can be lit or unlit, allowing endless possibilities with continuous ribbons of light

L80 B10 82,000 hours @35ºC
Proformax boards are CRI 90 as standard and have the highest efficiency currently on the market. The Proformax boards also have the lowest sulfurisation deteriorisation compared to other plastic based chips on the market.

L90 B10 114,000 hours @ 50*C
Xeramix 1 boards are both high output and high efficiency combined giving unmatched flexibility, by tuning the drive current any output is achievable

L70 B10 1,000,000 hours @35*C
Xeramix R boards are both high output and high efficiency combined giving unmatched flexibility, by tuning the drive current any output is achievable.

3000k_symbol4000k5000k<rgb_symbolrgbw_symboltuneable-white_symbolcyanosis_symbol

down_symbolup_symbol



click on selection above to view larger image

rod-suspension double-wire-suspended rod-suspension wall-mount ceiling-mount
single-suspension_symbol split-wire_symbol rod-fixing_symbol wall-mount_symbol ceiling-mount_symbol

135_symbolcross-90_symboltee-90_symbolcorner-90_symbolceiling-to-wall_symbolcustom_symbol

downlights_symbol sensors-daylight-harvesting_symbol emergency-packs_symbol

* Other options including custom colour matching available on request
Contact your nearest Distributor – xerolighting.com/contact

STANDARD COLOURS
Textured White  90133641 Textured White90133641
10 Micron Anodised Aluminium   10 Micron Anodised Aluminium
Textured Black  90132679 Textured Black90132679
RAL COLOURS
* Additional cost
RAL 9010
Pure White Satin
  PR12/40197/CS1
RAL 9010
Pure White Satin
PR12/40197/CS1
RAL 7035
Light Grey Satin
  PR12/60978/CS1
RAL 7035
Light Grey Satin
PR12/60978/CS1
RAL 9003
Signal White Satin
  PR12/40197/CS1
RAL 9003
Signal White Satin
PR12/40197/CS1
RAL 1015
Light Ivory Gloss
  PR12/941/C72
RAL 1015
Light Ivory Gloss
PR12/941/C72
RAL 7032
Pebble Grey Satin
  PR12/60232/CS2
RAL 7032
Pebble Grey Satin
PR12/60232/CS2
RAL 6002
Leaf Green Gloss
  PR12/20726/C12
RAL 6002
Leaf Green Gloss
PR12/20726/C12
RAL 9005
Jet Black Gloss
  PR12/710/C42
RAL 9005
Jet Black Gloss
PR12/710/C42
RAL 9004
Signal Black Matt
  PR18/7120/CM3
RAL 9004
Signal Black Matt
PR18/7120/CM3
RAL 5012
Light Blue Satin
  PR12/30670/CS5
RAL 5012
Light Blue Satin
PR12/30670/CS5
RAL 5005
Signal Blue Satin
  PR12/30263/CS6
RAL 5005
Signal Blue Satin
PR12/30263/CS6
RAL 1021
Colza Yellow Satin
  PR12/60464/CS6
RAL 1021
Colza Yellow Satin
PR12/60464/CS6
RAL 1018
Zinc Yellow Gloss
  PR12/159/C46
RAL 1018
Zinc Yellow Gloss
PR12/159/C46
RAL 1003
Signal Yellow Gloss
  PR12/134/C36
RAL 1003
Signal Yellow Gloss
PR12/134/C36
RAL 2000
Yellow Orange Gloss
  PR12/650/C38
RAL 2000
Yellow Orange Gloss
PR12/650/C38
RAL 2009
Traffic Orange Gloss
  PR12/6162/C21
RAL 2009
Traffic Orange Gloss
PR12/6162/C21
ANODISED FINISHES
* Additional cost
25 micron Annodised   25 micron Annodised
Grey Anodised   Grey Anodised
Black Anodised   Black Anodised
Green Anodised   Green Anodised
Gold Anodised   Gold Anodised
Blue Anodised   Blue Anodised
Red Anodised   Red Anodised
NON-STANDARD COLOURS
* Additional cost
alphatec classic white gloss  27281880 alphatec classic white gloss27281880
alphatec blaze blue gloss  98419941 alphatec blaze blue gloss98419941
alphatec french blue gloss  98432725 alphatec french blue gloss98432725
alphatec pommel blue gloss  98451034 alphatec pommel blue gloss98451034
alphatec space blue gloss  98419990 alphatec space blue gloss98419990
alphatec navy gloss  98450282 alphatec navy gloss98450282
alphatec dark violet gloss  98451926 alphatec dark violet gloss98451926
alphatec flame red gloss  98419959 alphatec flame red gloss98419959
alphatec signal red  98450735 alphatec signal red98450735
safety yellow gloss  9842015G safety yellow gloss9842015G
alphatec yellow gold gloss  98433617 alphatec yellow gold gloss98433617
alphatec lemon yellow gloss  98432120 alphatec lemon yellow gloss98432120
alphatec orange x15 gloss  98451439 alphatec orange x15 gloss98451439
alphatec mistletoe gloss  98451040 alphatec mistletoe gloss98451040
alphatec transformer grey gloss  98432186 alphatec transformer grey gloss98432186
Aztec Black  90182757 Aztec Black90182757
APO Grey Scylla  90136612 APO Grey Scylla90136612
Aztec Silver  90185040 Aztec Silver90185040
Black Scylla  90150003 Black Scylla90150003
Black texture  90132679 Black texture90132679
Copper Kinetic Pearl Satin  9717183K Copper Kinetic Pearl Satin9717183K
Graphite Sarouk  93551677 Graphite Sarouk93551677
Grey Hammer  90185184 Grey Hammer90185184
Gunmetal Kinetic Pearl Satin  9718115K Gunmetal Kinetic Pearl Satin9718115K
Horizon White Scylla  90151608 Horizon White Scylla90151608
Light Grey Scylla  90150766 Light Grey Scylla90150766
Mid Bronze Matt  27251014 Mid Bronze Matt27251014
Metropolis Silver Glow Gloss  97184623 Metropolis Silver Glow Gloss97184623
Notre Dame Scylla  90150223 Notre Dame Scylla90150223
Onyx Pearl Gloss  97152052 Onyx Pearl Gloss97152052
Pewter Pearl Satin  97188202 Pewter Pearl Satin97188202
Platypus Kinetic Pearl Satin  9717214K Platypus Kinetic Pearl Satin9717214K
Red Brown Scylla  90185473 Red Brown Scylla90185473
Silver Glow Pearl Gloss  97184623 Silver Glow Pearl Gloss97184623
Silver Grey Matt  27251272 Silver Grey Matt27251272
Silver Lode Pearl Texture  9017034Z Silver Lode Pearl Texture9017034Z
Silver Sarouk  93584874 Silver Sarouk93584874
St Elmos Fire Kinetic Pearl Satin  9717208K St Elmos Fire Kinetic Pearl Satin9717208K
Steel pearl Satin  97157127 Steel pearl Satin97157127
Stone Beige Scylla  90185474 Stone Beige Scylla90185474
Storm Grey Scylla  90150183 Storm Grey Scylla90150183
Zincshield Matt  9907036M Zincshield Matt9907036M
Shoji White Satin  27284682 Shoji White Satin27284682
clear gloss  91081797 clear gloss91081797
Charcoal Gloss  2729086G Charcoal Gloss2729086G
White Matt  96132312 White Matt96132312
Magnolia Gloss  27232658 Magnolia Gloss27232658
Olde Pewter Satin  27250243 Olde Pewter Satin27250243
Metropolis Storm Satin  97184684 Metropolis Storm Satin97184684
Primrose Scylla  9013005Z Primrose Scylla9013005Z
Classic Hawthorn Green Gloss  27233709 Classic Hawthorn Green Gloss27233709
Cottage Green Satin  27284219 Cottage Green Satin27284219
Mannex Suede, Texture  90137543 Mannex Suede, Texture90137543
APO Grey Satin  27232786 APO Grey Satin27232786
Berry Grey, Gloss  2727262G Berry Grey, Gloss2727262G
Citi Matt  97188471 Citi Matt97188471
JASPER satin  2728122S JASPER satin2728122S
armourspray velocity green  91033709 armourspray velocity green91033709
armourspray white gloss  91019143 armourspray white gloss91019143
barley gloss  2723089G barley gloss2723089G
barrister white satin  27284672 barrister white satin27284672
black Sarouk  93551146 black Sarouk93551146
black CB night sky satin  95981878 black CB night sky satin95981878
black satin  90109024S black satin90109024S
Black Gloss  2729090G Black Gloss2729090G
Black Matt  27219319 Black Matt27219319
blue ridge satin  27288480 blue ridge satin27288480
blue Hammer  90185159 blue Hammer90185159
bright silver metallic gloss  96151491 bright silver metallic gloss96151491
bright white gloss  27284636 bright white gloss27284636
canola cream satin  27281796 canola cream satin27281796
champagne Kinetic Matt  9713059K champagne Kinetic Matt9713059K
charcoal Metallic Pearl Gloss  97118796 charcoal Metallic Pearl Gloss97118796
charcoal satin  27288351 charcoal satin27288351
classic cream satin  2722095S classic cream satin2722095S
copper satin  9614137Q copper satin9614137Q
dark grey Matt  27251275 dark grey Matt27251275
deep brunswick green  2726134G deep brunswick green2726134G
deep ocean satin  2725125S deep ocean satin2725125S
dune satin  2723087S dune satin2723087S
duralloy white satin  2721139S duralloy white satin2721139S
evening haze satin  2723055S evening haze satin2723055S
ironstone satin  2727257S ironstone satin2727257S
light grey gloss  2727263G light grey gloss2727263G
magnolia Scylla gloss  90133618 magnolia Scylla gloss90133618
manor red satin  2724134S manor red satin2724134S
monument matt  9599066M monument matt9599066M
monument satin  2729067S monument satin2729067S
natural pearl matt  97189119 natural pearl matt97189119
notre dame gloss  27236672 notre dame gloss27236672
off white satin  27233732 off white satin27233732
olde pewter satin  26050243 olde pewter satin26050243
oyster matt  27236858 oyster matt27236858
paperbark satin  2723088S paperbark satin2723088S
pearl white gloss  2721114G pearl white gloss2721114G
precious nickel pearl matt  97188360 precious nickel pearl matt97188360
primrose gloss  27284365 primrose gloss27284365
rivergum beige gloss  27236991 rivergum beige gloss27236991
riversand matt  95936656 riversand matt95936656
shale grey satin  27283246 shale grey satin27283246
stone grey satin  27278126 stone grey satin27278126
streetwise silver satin  9107049Q streetwise silver satin9107049Q
surfmist matt  95984758 surfmist matt95984758
surfmist satin  2721137S surfmist satin2721137S
weathered copper matt  27233724 weathered copper matt27233724
wedgewood satin  27250279 wedgewood satin27250279
white birch gloss  27237131 white birch gloss27237131
wilderness satin  27284224 wilderness satin27284224
windspray satin  2727256S windspray satin2727256S
woodland grey matt  95951698 woodland grey matt95951698
woodland grey satin  272255S woodland grey satin272255S
X | TEK PREMIUM FINISHES
* Additional cost
Concrete Finishes
Charcoal Concrete   Charcoal Concrete
Polished Concrete   Polished Concrete
Light Concrete   Light Concrete


Rust Finishes


Desert Sand   Desert Sand
Edgy Auburn   Edgy Auburn
Earthy Ochre   Earthy Ochre
Morrocan Spice   Morrocan Spice

Woodgrain Finishes


Antique White   Antique White
Natural American Oak   Natural American Oak
Dark Mocha   Dark Mocha
Driftwood   Driftwood
European Walnut   European Walnut
Natural Blackbutt   Natural Blackbutt
Natural Bush Cherry   Natural Bush Cherry
Natural Casuarina   Natural Casuarina
Natural Chestnut   Natural Chestnut
Natural Curly Birch   Natural Curly Birch
Natural Ebony   Natural Ebony
Natural French Oak   Natural French Oak
Natural Golden Gum   Natural Golden Gum
Natural Golden Oak   Natural Golden Oak
Natural Ironbark   Natural Ironbark
Natural Jarrah   Natural Jarrah
Natural Kwila   Natural Kwila
Natural Maple   Natural Maple
Natural Silky Oak   Natural Silky Oak
Natural Snow Gum   Natural Snow Gum
Natural Spotted Gum   Natural Spotted Gum
Natural Tasmanian Oak   Natural Tasmanian Oak
Natural Teak   Natural Teak
Natural Wenge   Natural Wenge
Smoked Ash   Smoked Ash
Walnut Burl   Walnut Burl
Weathered Timber   Weathered Timber
Western Red Cedar   Western Red Cedar
Rose Mahogany   Rose Mahogany
African Blackwood   African Blackwood

0-10v_symboldali-control-gear_symboldsi-compatible_symboldmx_symboldimmer-switch_symbolconstant-light-output_symbolmotion-sensor_symbolripple-free_symbolbluetooth_symbol



*













* For this profile the Casambi mini interface is available for remote configuration only.

eess_symbolrcm-reg-mark-compliance_symbolssl_symbolccc_symbolce_symbolETL_approval XTA | 1.5 Beam

brochure_symbol
photometrics_symbol
sDoc EMC icon
cad-drawing_symbol
ies_report_symbol
data-sheet_symbol
brochure_symbol
brochure_symbol
xta-1-5-beam-product-image
xta-1-5-square-ip55-product-image
wire-suspension_symbol

* Casambi interface available in a remote configuration only

meet the family

XTA logo for website

XTA | 1.5 series

XTA logo for website

XTA | 1.5 IP-logo seriesIngress Protection IP55
