STANDARD SIZES
XTA | 2.0 Ellipse Slot 1426
Run length:3.958m
XTA | 2.0 Ellipse Slot 1991
Run length:5.215m
XTA | 2.0 Ellipse Slot 2226
Run length:6.472m
DOWNLOAD
SPECIFICATION
SHEET
for all 3 standard sizes
SPECIFICATION
SHEET
for all 3 standard sizes
DATA TABLE
| Optic Module LED Engine |
Proformax | CRI | 90+ |
| Lumen Maintenance | 82,000 Hours | ||
| Warranty | 7 years | ||
| Dimensions | (Profile size 60mm x 80mm) Ellispe sizes – 1426 x 1094mm / 1991 x 1329mm / 2226 x 1894 | ||
| Weight | XTA | 2.0 Ellipse Slot 1426 (10.4kg (22.92lbs) / XTA | 2.0 Ellipse Slot 1991 (15.1kg (33.20lbs) / XTA | 2.0 Ellipse Slot 2226 (17.2kg (37.91lbs) |
||
| IP Rating | IP20 (dry indoor application only) | ||
| Compatible ceiling type | Suitable for gyprock (drywall) ceilings, metal pan, concrete, timber and T-bar grid ceilings | ||
| Mounting | Wire suspensions, rod suspensions, surface mounting, ceiling mounting | ||
To create fully customisable variations of this profile
go to – XTA | 2.0 Loop Slot
meet the family
XTA | 2.0 ELLIPSE SERIES
