XTI | 2.0 R Recessed | IP66 | IK11 – Size: 2.36” (3.03“ including flange) Wide x 3.93” Highintegral gear continuous
PRODUCT OVERVIEW
![](https://xerolightingusa.com/wp-content/uploads/2023/01/Front-View_XTI_2_0_Recessed.x66874.png)
![](https://xerolightingusa.com/wp-content/uploads/2017/06/Proformax-7-years_logo-1.x66874.png)
DATA TABLE
Output
|
CRI | 80+ | |||
Warranty | ProformaxS | ProformaxS = 7 years | |||
Electrical | Voltage input range | 120 – 277V | |||
Control methods | Dimming options for white light: 0-10V, DALI, DMX Optional RGB / Sunset Dimming control DMX or DALI XI |
||||
Approvals | UL / CE / CCC / AS:NZS / EMC | ||||
Physical | Dimensions | 2.36” (3.03“ including flange) Wide x 3.93” High | |||
Weight | 3.33 lbs average weight per foot | ||||
Housing | Aluminium Extrusion with anodised or powder-coated finish Standard colours powder-coated: white/black/silver/ custom on request | ||||
Diffuser | Polycarbonate Opal Diffuser/ Clear Polycarbonate Diffuser / Parabolic Louvre | ||||
Connections | Optional IP Rated polarised electrical connection between sections | ||||
Compatible ceiling type | Suitable for drywall ceilings, metal pan, concrete, timber and T bar grid ceilings | ||||
Mounting | Wire Suspension, Surface mount (with external bracket), Wall Blocks, End wall Bracket | ||||
Joiner options | (Non lit) 90º Butt bend / Tee Butt bend | ||||
Operating temperatures | ProformaxS (-13ºF to 140ºF) | ||||
Environment | Luminaire IP66 (Not in direct sunlight, diffuser must not face upwards). | ||||
IK rating | IK11 | ||||
Minimum length adjustment | 5.51″ | ||||
LED board types | ProformaxS boards and drivers in 3.93″ / 11.02″ / and 22.04″ Zhaga compatible | ||||
Vandal-proof | Available with anti-vandal fasteners | ||||
Optional extras | Lanyards / Emergency packs / Camera / Environmental Plugs / Thermal throttle / IOT connectivity / Anti-Graffiti / Self Cleaning Coating / Halogen Free Diffuser / Anti Bird Roosting |
![](https://xerolightingusa.com/wp-content/uploads/2023/01/XTI-Available-Lengths-2-4.x66874.png)
